China Long Handle Grip Pickleball Paddle Exporter
This product page details the technical characteristics of extended‑handle pickleball paddles manufactured for export from China. The information focuses on measurable attributes that influence performance, durability, and suitability for various buying organizations.
Design and Dimensions
The paddle features an overall length of 400 mm (±2 mm) with a hitting surface width of 190 mm (±1 mm). The extended handle measures 140 mm from the butt cap to the start of the paddle face, providing a two‑handed grip option for players who prefer additional leverage.
Grip circumference is available in three standard sizes: 100 mm, 106 mm, and 112 mm (±0.5 mm). The handle core is constructed from a 6 mm thick polypropylene honeycomb, contributing to a weight range of 210 g to 235 g depending on face material selection.
Face and Core Materials
The hitting surface can be specified as either 7‑layer carbon fiber weave (areal weight 180 g/m²) or 2‑layer fiberglass composite (areal weight 220 g/m²). Both options are bonded to the polypropylene honeycomb core using a heat‑activated epoxy film that cures at 150 °C for 8 minutes.
Edge protection is provided by a 2 mm thick TPU rim, molded integrally with the face laminate to prevent delamination under repeated impact.
Typical Specifications
| Attribute | Typical Value | Adjustable Range |
|---|---|---|
| Overall Length | 400 mm | ±2 mm |
| Handle Length | 140 mm | 120 mm‑160 mm |
| Weight | 220 g | 210 g‑235 g |
| Balance Point (from butt cap) | 190 mm | 175 mm‑205 mm |
| Face Material | Carbon Fiber | Carbon Fiber / Fiberglass |
| Core Thickness | 6 mm | 5 mm‑8 mm |
Manufacturing Process
Paddle blanks are produced by placing pre‑impregnated carbon or fiberglass sheets onto a polypropylene honeycomb core, then hot‑pressing at 150 °C under 1.2 MPa pressure for 8 minutes. The TPU edge rim is injection‑molded onto the pressed blank in a secondary operation to ensure a uniform bond.
After curing, each paddle undergoes CNC trimming to achieve the final face dimensions (±0.2 mm) and handle shaping to the specified grip circumference. Surface finishing includes a UV‑curable clear coat (30 µm thickness) to enhance abrasion resistance.
Quality Assurance
Dimensional checks are performed on a coordinate measuring machine with a repeatability of ±0.01 mm. Weight is verified using a precision scale (0.01 g resolution). Balance point is measured by pivoting the paddle on a low‑friction fulcrum and recording the equilibrium position.
Impact resistance is evaluated per ASTM F2792‑19 using a 42 mm diameter steel ball dropped from 1.0 m height; acceptable paddles show no delamination or crack propagation after 100 cycles. All test results are retained for traceability and can be supplied upon request.
Applications and Benefits
The extended handle shifts the mass distribution toward the butt cap, increasing moment of inertia about the wrist axis. This characteristic benefits players who rely on two‑handed backhand strokes or who require additional reach for defensive volleys.
Educational institutions and community centers often select this configuration for beginner programs because the longer grip reduces wrist strain during prolonged play sessions. Commercial distributors value the paddle’s consistent weight tolerance (±7 g) which simplifies inventory forecasting.
Customization Options
- Face material: carbon fiber, fiberglass, or hybrid laminate
- Core thickness: 5 mm to 8 mm in 0.5 mm increments
- Handle length: 120 mm to 160 mm
- Grip circumference: 90 mm to 120 mm
- Edge guard color: black, white, or custom Pantone
- Surface graphics: full‑color UV printing, laser etching, or sublimation
- Logo placement: butt cap, throat, or face center
- Packaging: individual PE bag, inner box, master carton (12 pcs/ctn)
Frequently Asked Questions
Can dimensions be customized?
Yes. Overall length, handle length, grip circumference, and core thickness can be adjusted per project requirements. Custom tooling may be required for lengths outside the standard 120 mm‑160 mm handle range.
What information is needed for a quotation?
To generate a quote we require: desired face material, core thickness, handle length, grip size, edge guard color, logo artwork (vector format), order quantity, and preferred INCOTERMS.
What is the typical production lead time?
Lead time averages 18‑22 working days after receipt of approved artwork and deposit, depending on order size and current factory capacity.
How are export shipments protected?
Paddles are packed in individual polyethylene bags, placed in corrugated inner boxes with 5 mm foam padding, then stacked in export‑grade cartons meeting ISPM‑15 standards. Cartons are strapped and stretch‑wrapped for palletization.
