Best Price Top Rated Pickleball Nets Factory
Our factory produces pickleball nets designed for court installations that require consistent tension, UV resistance, and easy replacement. Each net is built from polyethylene mesh with reinforced
Pickleball Net Systems – Factory Direct Pricing
Our factory produces pickleball nets designed for court installations that require consistent tension, UV resistance, and easy replacement. Each net is built from polyethylene mesh with reinforced border tape and stainless‑steel hardware to meet recreational and tournament specifications.
Construction Details
The net body uses 1.5 mm twisted polyethylene yarn, providing a breaking strength of approximately 220 N per strand. The mesh opening is 45 mm square, which balances ball visibility with wind resistance. Border tape is 50 mm wide PVC‑coated polyester, sewn with double‑needle stitching to prevent fraying.
Support poles are extruded aluminum with a wall thickness of 2 mm, finished with an anodized coating rated for 500 hours of salt‑spray exposure. Ground sleeves are hot‑dip galvanized steel, 100 mm diameter, allowing for quick‑release installation.
Performance Specifications
- Net height adjustable from 0.91 m to 1.07 m via cam‑lock mechanism.
- Tension system maintains ≤5 mm deflection under a 150 N load.
- UV stabilizer additive provides ≥2000 hours of outdoor exposure before 10 % loss in tensile strength.
- Weight of complete net system (net, poles, hardware) ≈ 12 kg.
Customization Options
Customers can specify mesh color (standard white, high‑visibility yellow, or custom dye lots), border tape width (25 mm to 75 mm), and pole length (2.4 m to 3.0 m) to match court dimensions. Hardware upgrades include nylon cam‑locks or stainless‑steel ratchets.
Typical Applications
Pickleball nets are installed on dedicated courts, multi‑use sport surfaces, and temporary event venues. The design accommodates frequent net tension adjustments required for league play and allows rapid removal for court conversion to other activities.
Quality Assurance
Each production lot undergoes visual inspection of seam integrity, dimensional verification of mesh opening using a calibrated gauge, and pull‑test of border tape to confirm adhesion strength ≥15 N/mm. Final assembly is checked for pole alignment and cam‑lock operation before packaging.
Specification Table
| Parameter | Typical Value | Adjustable Range |
|---|---|---|
| Mesh yarn diameter | 1.5 mm | 1.2 mm – 2.0 mm |
| Mesh opening | 45 mm square | 30 mm – 60 mm |
| Border tape width | 50 mm | 25 mm – 75 mm |
| Pole material | Anodized Al 6063 | Optional SS 304 |
| Net weight | 12 kg | 10 kg – 15 kg |
Frequently Asked Questions
Can dimensions be customized? Yes, net length, height, and pole length can be adjusted to meet specific court layouts; provide exact measurements when requesting a quote.
What information is required before quotation? Court dimensions, desired net color, any hardware preferences, and order quantity.
What materials are available for the mesh? Standard polyethylene with UV stabilizer; optional polypropylene for higher abrasion resistance.
How is quality inspected? Visual seam check, mesh gauge verification, tape adhesion pull‑test, and functional cam‑lock test.
What packaging methods are available? Nets are rolled and placed in polyethylene bags with corrugated corner protectors; palletized for bulk shipments.
What is the typical production lead time? 2‑3 weeks for standard configurations; 4‑5 weeks for customized colors or special hardware.
Contact for Quote
To receive a detailed quotation, please share your project specifications via our inquiry form. We will respond with pricing, lead time, and any relevant technical data.
